1. The precision ball bearing is secured in the steel stamped bearing housing. The bearing is tight and durable. Able to withstand greater axial forces than a plastic bearing unit.
2. The environmental working conditions are broad. They can be used in both high and low temperature applications.
3. Complete range of tube diameters available. High load capacity.
4. Anti-static design.
5. Not suitable for carring roller & tensioning position of belt conveyor.
6. Temperature range:-5℃ ~ +40℃,Remove the retaining ring on
both sides (black), the temperature can reach -30 ℃ ~ +80 ℃.
D | T | Shaft | Tube |
Steel Z/P | SS | Aluminium |
Φ50 | 1.5 | Φ12/15 | √ | √ |
|
Φ50 | 2.0 | Φ12/15 | √ |
| √ |
Φ60 | 2.0 | Φ12/15/20 | √ | √ |
|
Φ60 | 3.0 | Φ15/17 | √ |
| √ |
| Φ80 | 2.0 | Φ20 | √ |
|
|
Φ80 | 3.0 | Φ20 | √ |
|
|
| Φ80 | 4.0 | Φ20 |
|
| √ |
| Φ89 | 3.0 | Φ20 | √ |
| √ |
Φ89 | 4.0 | Φ20 | √ |
|
|
Remark: Φ50 rollers can be fitted with PU sleeve (2mm).
Φ50、60 rollers can be fitted with PVC sleeve (2mm).
11hex can provide tapered plastic steel shaft sleeve roller.
